Farley 5 is a go-anywhere fat bike built for snow, sand, and rugged trail missions. Updated geometry with a slacker head tube and steeper seat tube adds stability and pedaling efficiency. A carbon fork with multiple mounts lets you gear up for the long haul, while wide, grippy tires keep you floating through deep snow, soft sand, and everything in between.
- Frame
- Alpha Platinum Aluminum, tapered head tube, top tube bag mounts, strapless full frame bag mounts, downtube fender mount, lower downtube accessory mount, seat stay rear rack mounts, internal rear derailleur & dropper post routing, threaded BB, UDH, 197x12mm
- Fork
- Farley carbon, tapered alloy steerer, crown rack mounts, lower leg cage mounts, 150x15mm thru axle
- Hub front
-
Bontrager alloy, sealed bearing, 6-bolt, 15x150mm thru axle
- Skewer front
-
Bontrager Switch thru axle
- Hub rear
-
Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano 10 freehub, 197x12mm thru axle
- Skewer rear
-
Bontrager Switch thru axle
- Rim
-
SUNRingle Mulefut 80 SL, 32-hole cutout
- Tire
-
Bontrager Gnarwhal Team Issue, Tubeless Ready, Inner Strength sidewalls, studdable, aramid bead, 120 tpi, 27.5x4.50''
- Max tire size
- 27.5x4.50"
- Shifter
-
microSHIFT Advent X SL-M9605, 10 speed
- Rear derailleur
-
microSHIFT Advent X RD-M6205AM, 48T max cog
- *Crank
-
Size: S, M, L
FSA Comet, 30T, 170mm length
Size: XL
FSA Comet, 30T, 175mm length
- Bottom bracket
-
FSA BB-7100, 100mm, BSA threaded
- Cassette
-
microSHIFT Advent X, 11-48, 10 speed
- Chain
-
- Pedal
-
- Max chainring size
- 1x: 32T
- Saddle
-
Bontrager Verse P3, steel rails
- *Seatpost
-
Size: S
TranzX JD-YSP18, 100mm travel, internal routing, 31.6mm, 361mm length
Size: M
TranzX JD-YSP18, 130mm travel, internal routing, 31.6mm, 425mm length
Size: L, XL
TranzX JD-YSP18, 150mm travel, internal routing, 31.6mm, 470mm length
- Handlebar
-
Bontrager alloy, 31.8mm, 15mm rise, 750mm width
- Grips
-
Bontrager XR Trail Comp, nylon lock-on
- *Stem
-
Size: S
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length
Size: M
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length
Size: L, XL
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 70mm length
- Headset
-
FSA IS-2, 1-1/8" top, 1.5" bottom
- Brake
-
SRAM Level hydraulic disc
- Brake rotor
-
Avid G2 CleanSweep, 6-bolt, 160 mm
- Brake Set
-
SRAM Level hydraulic disc
- Rotor size
- Max brake rotor sizes: 180mm front & rear
- Weight
- M - 16.20 kg / 35.72 lbs (with tubes)
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
