Frameset

Frame - Alpha Gold Aluminum, internal cable routing, internal battery, rack & fender mounts, flat mount disc brake, kickstand mount, 144.5mm OLD hub motor spacing
Fork - Alloy, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm bolt-on skewer

Wheels

Hub front - Alloy low-flange w/6-bolt disc, 36h, w/QR
Skewer front - 132x5mm QR, ThruSkew
Rim - Alloy double wall, 36h
Tire - Bontrager GR0 Comp, wire bead, 60 tpi, 650x50mm
Max tire size - 650x50mm

E-system

Battery - 520Wh, integrated in down tube
Charger - Trek Easy Mag charger, 2.7A, 54.9V output, 100V-240V AC input
Computer - LCD display
Motor - Hub drive motor, 60 Nm, 500W, 36H, black

Drivetrain

Shifter - Shimano M315, 8 speed
Rear derailleur - Shimano ESSA U2000
Crank - Alloy, 40T steel chainring, 170mm length
Cassette - Shimano HG400, 11-45, 8 speed
Chain - KMC Z8.3
Pedal - Bontrager City pedals
Max chainring size - 1x: 40T

Components

Saddle - Bontrager Sport Women's
*Seatpost
Size: S, M - Bontrager alloy, 31.6mm, 12mm offset, 330mm length
Size: L - Bontrager alloy, 31.6mm, 12mm offset, 400mm length
*Handlebar
Size: S, M - Bontrager alloy, 31.8mm, 15mm rise, 690mm width
Size: L - Bontrager alloy, 31.8mm, 15mm rise, 720mm width
Grips - Bontrager XR Endurance Comp, lock-on
*Stem
Size: S, M - Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
Size: L - Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length
Brake - Rush BH-286 hydraulic disc, 180mm rotor
Rotor size - Max brake rotor sizes: 180mm front & rear

Accessories

Light* - Herrmans MR8, 180 lumen, 60 lux, LED headlight
Sate-Lite M-15 with turn signal and brake light function
Kickstand - Alloy, rear mount

Weight

Weight - M - 22.00 kg / 48.51 lbs
Weight limit - This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
